3D printed pipe adapter

Tailor-made solutions for efficient production processes

In the modern manufacturing industry, efficiency is the key to success. Companies are faced with the challenge of continuously optimising their production processes in order to remain competitive. 3D printing is becoming increasingly important due to its speed, flexibility and cost efficiency. By using 3D printed adapter cones, we have been able to optimise our internal production processes, saving time, costs and resources, which has led to a significant increase in the efficiency of production steps.

Perfect fit for a smooth industrial vacuum system

Adapter cones are used in industrial dust extraction systems to adapt different pipe diameters in suction and pressure lines. They can be used to enlarge small diameters to large diameters and to reduce large diameters. This is particularly useful when adapting accessories & peripherals, e.g. from third party manufacturers, whose diameters do not fit ex works.

Adapter cones are used in industrial dust extraction systems to adapt different pipe diameters in suction and pressure lines. They can be used to enlarge small diameters to large diameters and to reduce large diameters. This is particularly useful when adapting accessories & peripherals, e.g. from third party manufacturers, whose diameters do not fit ex works.

In the past, adapting different pipe adapter diameters was done using tape and manual deformation. Not only does this involve manual effort and handling, but it does not meet the quality standards required in demanding production environments.

3D printing, on the other hand, with its high degree of design freedom, allows the geometry to be flexibly adapted so that the adapter can be adapted to different pipes. This allows different components to be seamlessly integrated. With its high degree of design freedom, 3D printing can provide a customised, seamless solution in a reliable and resource-efficient manner.


Precisely fitting materials: TECAFIL for optimised production solutions

In addition to customisation to the individual pipe adapter diameters, material-specific criteria also play an important role in production. The 3D printed adapter cones must be able to withstand high mechanical and chemical loads and at the same time be light and easy to manufacture and install. With our extensive portfolio of high-performance and engineering filaments from our own production, we can tailor the materials used precisely to the required criteria.

Our pipe adapter cone is made of TECAFIL PA6 GF30 black. This innovative material offers a wide range of applications and is characterised by its robustness and reliability. PA6 GF30 can be printed on low-cost engineering printers such as the Ultimaker or similar models. TECAFIL PA6 GF30 black thus offers an ideal combination of strength, reliability and processability for efficient and reliable adapter cones in industrial applications.

PA filament TECAFIL PA6 GF30 black 1,75 Teaser
TECAFIL PA6 GF30 black - 1,75 mm

material-specific advantages

Robustness and reliability:

TECAFIL PA6 GF30 black is extremely resistant to mechanical stress and wear.

Temperature & chemical Resistance:

It remains stable and reliable even at extreme temperatures and in environments with aggressive chemicals.

Excellent printability & handling:

TECAFIL PA6 GF30 black can be easily processed on commercially available printers, enabling cost-effective on-site production.

Low weight, high strength:

Despite its strength, the material is lightweight, which facilitates handling and installation.

Precise adaptation, seamless integration - 3D printing for your production optimisation

Innovation and efficiency in production are crucial for long-term success. By continuously searching for new solutions, companies can strengthen their competitiveness and consolidate their market position. The use of state-of-the-art technologies such as 3D printing and high-quality materials makes it possible to offer first-class products and react flexibly to market changes. With our 3D printing service and comprehensive filament portfolio, we help you to make the most of these advantages.

High-performance filaments and customised solutions: Ensinger Additive Manufacturing

Diverse material selection and strength:

We offer a wide range of material options in the field of high-performance filaments, ideal for industrial applications.

Precision and quality:

Our solutions are high-precision components of consistent quality, exactly to your requirements.

Time and cost savings:

Our 3D printed parts can speed up production processes and reduce costs, whether through shorter production times, lower material consumption or less waste.

Industry-specific customisation:

We offer tailor-made solutions for specific industries or applications by focusing on individual requirements and challenges.

Innovative technology and progress:

We invest in advanced manufacturing techniques and material innovations to offer the latest trends and developments and help you stay at the forefront of your industry.

Complete solutions from a single source:

In the Ensinger One-Stop Shop, we offer the entire value chain - from the compound to the ready-to-install 3D printed part - in-house and from a single source.

Your partner for 3D printed industrial parts

Take advantage of the benefits of 3D printing and contact us today for customised solutions for your industrial requirements.
